Model

GN-TSHR6-ST200M-4GS

CPU

Hi3516E V200

Sensor

1/2.8" SONY Starvis CMOS IMX307

Resolution

2MP (1920*1080)

APP & CMS

 Mobile- APP:  CamHi    PC- CMS : HiP2P

Lens

4.7mm~94mm

ZOOM

20X Optical Zoom

Minimum illumination

0.01Lux

Day/night mode

Support IR-cut

IR distance

150M

Storage function

Support TF card storage, Max 128G

Motion detection

4 separate test areas can be set （ Sensitivity can be set）

Alarm linkage

Send pictures by Email; pictures and videos uploaded to the FTP server;

Manual speed

0.5-100°/S

Preset speed

100°/S

OSD

OSD name, time, date, information overlay

Video processing

Support H.265 / H.264

Network interface

1 RJ45 Ethernet interfaces ,10/100M self-adaption;

Suppert:CP/IP，HTTP，TCP，ICMP，UDP，ARP, IGMP，SMTP，FTP，DHCP，DNS，DDNS，NTP，UPNP，RTSP

Band information

WiFi AP：802.11/b/g/n

TDD-LTE：Band 38/39/40/41

FDD-LTE：Band 1/3

WCDMA: B1/B8

TD-SCDMA: Band 34/39

GSM/GPRS/EDGE: 900/1800

Preset

128

A-B Scan

1

cruise

4 groups

Preset number of cruise groups

10 preset/ groups

waterproof

IP66

Lightning protection

4000V

Working temperature

(-20℃～+60℃)

Grosss Weight

3.9KG
