GN-SKY60 FishEye Camera





GN-SKY60 FishEye Camera


General Features:

HD 4 IN 1 FishEye Camera
Support AHD/TVI/CVI/CVBS
Resolution: 2MP / 5MP / 8MP
Al-Alloy IP66 Housing
FishEye 1.8mm Lens(1.44mm optional)
3pcs Array IR LED, 25M IR Range






Camera

Model NO.

GN-SKY60-HD200

GN-SKY60-ST200

GN-SKY60-SY500

GN-SKY60-SY800

Image Sensor

SONY IMX323
(1/2.9" CMOS)

SONY Starvis IMX307
(1/2.8" CMOS)

SONY IMX326
(1/2.8" CMOS)

SONY 415
(1/2.8" CMOS)

DSP

FH8536H

FH8536H

FH8538M

FH8538M

Image Resolution

1080P

1080P

5MP

8MP

Effective Pixels

1920(H)x1080(V)

1920(H)x1080(V)

2704(H)x1950(V)

3840(H)x2160(V)

TV System

PAL / NTSC

Electronic Shutter

1/25s~1/50,000s , 1/30s~1/60,000s

Sync System

Internal

Usable Illumination

0.01Lux

0.001Lux

0.01Lux

0.01Lux

S/N Ratio

50dB

52dB

52dB

52dB

Scanning System

Progressive Scan

Video Output

4 IN 1,  AHD/TVI/CVI/CVBS

Lens

Focus Length

1.8mm  (1.44 mm is optional)

Focus Control

Fixed

Lens Type

Fish Eye Lens

Night
Vision

Infrared LED

3pcs Array IR-LED

Infrared Distance

20-25M

IR Status

Under 10 Lux by CDS

IR Power On

CDS Auto Control

Day/Night

Auto (ICR) / Color / B&W

Camera Features

OSD Menu

Yes

OSD Menu Language

EN, CN, ES, FRA, IT, RU, PT, JP, KR

White Balance

Auto/Manual

Auto/Manual

Auto/Manual

Auto/Manual

Gain Control

Auto

Auto

Auto

Auto

Noise Reduction

3D NR

3D NR

3D NR

3D NR

WDR

DWDR

DWDR

DWDR

DWDR

Picture Adjustment

Yes

Yes

Yes

Yes

General

Camera Housing

Al-Alloy, IP66

Operation Temperature

-10 ~ +50 RH95% Max

Storage Temperature

-20 ~ +60 RH95% Max

Power Source

DC12V±10%,  500mA

Dimension

188(W) x65(H) x65(D)mm

Gross Weight

0.4Kg
